Digital Multimeter LCR-Reader-R3 with multiligual Interface: LCR-Meter, Diode/LED Tester, Signal Generator (Yellow)
Product details
| Management number | 212004152 | Release Date | 2026/04/06 | List Price | $120.00 | Model Number | 212004152 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
LCR-Reader R3 is a fully automatic and manual multi tester with 0.1% basic accuracy with a wide selection of test functions and features including 100 kHz test frequency. When set to ‘Auto mode’, R3 automatically determines the type of component and best test parameters before measuring with high accuracy. All measurement values are instantly displayed. R3 is well suited for virtually any task involving SMT or PCB debugging. It is an exceptional tool for testing large Capacitances up to 1F. Electrolytic capacitors are measured at 120 Hertz with ESR measured at 100 kHz in accordance with regular electrolytic capacitor test conditions. While used with the LCR-Reader Kelvin Probe Connector, turns the R3into a low-frequency probe station. Features: Grey backlit LCDFully automatic & manual LCR, ESR, LED/Diode measurements0.1% Basic AccuracyAutomatic & manual test frequencies; including 100, 120 Hz, 1, 10, & 100 kHzTest signal levels of 0.1, 0.5 & 1.0 VrmsEasy Open/Short Calibration and offset removalLED testing with 3.2 VoltsSignal Generator with Sine wave up to 100 kHz200 Ohms Signal Source Resistance Displays active & reactive impedance componentsGold-plated test leads1.3 oz. weightLi-Po battery & micro-USB charging portHandles components to 0201 size4-way joystick navigation button
- LCR-meter, LED/Diode
- 0.1% Basic Accuracy
- English/German/French/Italian/Spanish/Chinese Interface
- Test Frequencies from 100 Hz to 100 kHz
- Large and Super Capacitance Testing to 1F
| Color | Yellow |
|---|---|
| Brand Name | LCR-Reader |
| Style Name | Yellow |
| Item Weight | 1.3 Ounces |
| Manufacturer | Siborg Systems Inc. |
| Power Source | Battery Powered |
| Item Dimensions | 6.54 x 0.91 x 0.55 inches |
| Specification Met | NIST, RoHS |
| Included Components | case, charger, charging cable, quick start manual |
| Upper Temperature Rating | 50 Degrees Celsius |
| Maximum Operating Voltage | 0.5 Volts (AC) |
| Minimum Operating Voltage | 4 Volts (AC) |
